TITAN Router
T-1325-SV
Professional CNC router. Spindle HSD 6.0 KW - 24,000 RPM. Vacuum table with 7.5 KW vacuum motor power.
Request price & availability
Features & Benefits
Industrial CNC Router with Top Quality components.
Italian Spindle 6.0 KW loaded with high speed bearing technology for smoothness and low noise.
Japanese Jaskawa Servo Motors 750 W. German Helical Pinion Rack. Japanese Shimpo Reducer. Vacuum table with 7.5 KW vacuum motor.
Automatic bearing lubrication system to maintain mechanical parts.
Weight and Dimensions
- Net: 0 LB
- Gross: 0 LB
- Pack:
Specifications
| Effective working area: | X=1300mm / Y=2500mm / Z=200m |
| Table structure: | Taiwan Hiwin Square 20mm |
| Driving Method: |
X/Y: Pinion rack. Z: Ballscrew |
| Reducers: |
Japanese Shimpo |
| Motors: | Japanese Jaskawa Servo Motors 750 W |
| Vacuum system: | 7.5 KW |
| Spindle: | Italian HSD 6.0KW - 18,000 RPM. |
| Max air move: | 40,000 mm/min |
| Max working move: | 25,000 mm/min |
| Software: | Ucancam / HPGL |
| Voltage: | 220v/380v - 50/60Hz, 3 Phase |
| Control system: | NK105 |
